BMS 8S 24V LiFePo4 30A Battery Protection Board with Balance – Short Circuit, Overcharge & Overdischarge Protection

Goo Gadget

BMS 8S 24V LiFePo4 30A Battery Protection Board with Balance – Short Circuit, Overcharge & Overdischarge Protection
  • BMS 8S 24V LiFePo4 30A Battery Protection Board with Balance – Short Circuit, Overcharge & Overdischarge Protection_img_0
  • BMS 8S 24V LiFePo4 30A Battery Protection Board with Balance – Short Circuit, Overcharge & Overdischarge Protection_img_1

BMS 8S 24V LiFePo4 30A Battery Protection Board with Balance – Short Circuit, Overcharge & Overdischarge Protection

850 BDT990 BDTSave 140 BDT
1

Specification:

Battery Type: LiFePo4 (Lithium Iron Phosphate)

Configuration: 8S (8 cells in series) – 24V nominal

Continuous Discharge Current: 30A

Charge Voltage: 29.2V (max)

Balance Function: Yes, active cell voltage balancing

Protection Features: Overcharge, overdischarge, short circuit, and overcurrent protection

Operating Temperature: -20°C to +60°C

PCB Size: Approx. 90 × 55 × 10 mm

Weight: Approx. 40g

Applications: E-scooters, e-bikes, solar storage, LiFePo4 battery packs



---

Description:

This 8S 24V 30A LiFePo4 BMS (Battery Management System) is designed to protect and manage your lithium iron phosphate battery pack. It supports 8 cells in series and features a balance function to ensure equal voltage across all cells, extending battery life. With overcharge, overdischarge, overcurrent, and short circuit protection, it keeps your battery safe and reliable. Perfect for e-scooters, e-bikes, solar storage systems, and other 24V LiFePo4 battery applications.


---

Application:

E-scooter battery packs

E-bike power systems

Solar energy storage

24V LiFePo4 UPS systems

DIY lithium battery projects
